Smart prepayment energy meter - QE530

Quill Energy smart energy meter QE530 المباني الذكية
QE530 Front
QE530 bottom.jpg
QE530 Side.jpg

Generation 5 smart prepayment energy meter. Remote communication through our AMI system or using or backup IC-card in case of network interruption. Securing availability to meter at all times.

Switch between prepaid and postpaid meter easily. Tariff and customer fee deduction from meter in prepaid mode and from system when running post-paid mode.

Highest quality build in the market with top end material.

Overview

Electricity bill prepaid postpaid.gif

Postpaid / Prepaid

Convert meter payment mode at anytime during operation

Firmware remote update.gif

Firmware update

Remote firmware update in bulk with activation date

Communication module.png

Communication module

Plug and Play: GPRS, G3-PLC, RS485, RF

myQuill app Quill Energy.jpg

myQuill App

Integrates with app for instant readings, debt and payments

Quill Energy smar IC card NFC.gif

Backup IC-card

Connect to meter incase network interruption


DLMS/COSEM

International standard for utility meter data exchange

Remote communication.png

Remote communication

Send any configuration or retrieve data remotely


STS

Standard Transfer Specification

Highest token security

Specifications

Measurement

○ Compliance with IEC and EN standard:

IEC 62053-22 / IEC62053-23 / IEC 62052-11 /  IEC 62055-31

○ Connection type: 3P4W DT

○ Accuracy: Cl (0.5) for active – CL(B) for reactive

Voltage

○ Nominal voltage: 3x220/400V

○ Operating range: 0.8Un to 1.2 Un

○ Power consumption: Voltage circuit ≤ 2W, 10VA

○ Current circuit ≤ 6 VA

Current

○ 5(100)A / 10(100)A

Frequency

○ 50Hz (± 5%)

○ Real-Time Clock (RTC)

○ Accuracy within 0.5 seconds per day at 23°C

LCD Display

○ 8 characters of 7 segment display

○ Digital size: 4mm x 8.2mm

○ LCD display available without main power

○ Programmable display items

○ With backlight

LED Display

○ Active pulse LED (1000)

○ Alarm LED

○ Credit LED

○ Buzzer for low/no money

Battery

○ Battery easy replaced

○ Voltage: 3.6V

○ Backup time: 10 years with power

○ GPRS with supercapacitor

Measured Values

○ Active Energy (kWh) (Import/Export)

○ Active Power (kW) (Import/Export)

○ Instantaneous Irms, Vrms, Frequency, Power Factor, Max power

Tariffs

○ 10 consumption step-tariff

○ 10 customer fee step-tariff

○ Flat-Rate & TOU

Relay

○ 120A

Event Logs

○ Tampering detection, power quality and general events

Card property

○ CPU 32 KB capacity

○ Read and write

○ Lifespan: 15 years

○ Compliance with IEC standard

Communications

○ Near-infrared communication

port: 1200~9600bps IEC 62056-21 E mode

○ RS485 comm. port: 9600bps DLMS HDLC

○ GPRS DLMS TCP/IP

Environmental

○ Operating range limit: -40°C to +70°C

○ Storage range limit: -40°C to +80°C

○ Relative humidity: ≤ 95%RH

○ Ingress protection: IP54

Dimensions and Weight

○ Dimensions: 290mm x   170mm x 85mm

○ Weight: 2.2kg (Approx.)
